4 x Gigabit PoE/PoE+ ports
4 x Gigabit ports
Reduces equipment cost by delivering data and power over existing network cables
16 Gbps switching capacity
Sturdy metal case
Up to 75% GREENnet power savings
Up to 30 Watts per port with a 60 Watt total power budget

SPEC
Standard
IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.3u 100Base-TX
IEEE 802.3ab 1000Base-T
IEEE 802.3at Power over Ethernet (PoE+)
IEEE 802.3af Power over Ethernet (PoE)
IEEE 802.3X Flow Control
IEEE 802.3az Energy Efficient Ethernet
Ports
4 x Gigabit Auto-MDIX PoE+ RJ-45 ports4 x Gigabit Auto-MDIX RJ-45 ports
Data Transfer Rate
Ethernet: 10/20 Mbps (Half/Full Duplex)
Fast Ethernet: 100/200 Mbps (Half/Full Duplex)
Gigabit: 2000 Mbps (Full Duplex)
Forwarding Rate
11.9 mpps (based on 64-byte packet size)
Data RAM Buffer
96K bytes
Address Table
1K MAC entries
Switch Fabric
16 Gbps
Power
Input: 100-240 V AC 50/60 Hz, 1.5 A
Output: 56 V DC, 1.16 A External Power Adapter
Diagnostic LEDs
Power, PoE, 1000 Mbps, Link/Activity
Power Consumption
Min: 4 Watts (standby)
Max: 65 Watts
PoE Max: 60 Watts
(4 x 15 watts PoE devices connected or 2 x 30 watts PoE+ devices connected)
Temperature
Operating: 0° ~ 40°C (32° ~ 104°F)
Storage: -20° ~ 90°C (-4° ~ 194°F)
Humidity
Max. 90% (non-condensing)
Dimensions
142 x 95 x 30 mm (5.6 x 3.7 x 1.2 in.)
Weight
380 g (13.4 oz.)
Certifications
CE, FCC
PoE
Power over Ethernet
Up to 15.4 watts for PoE
Up to 30 watts for PoE+
PoE: pin 1,2 for power+ and pin 3,6 for power- (mode A)
