Reduces equipment cost by delivering data and power over existing network cables
4 PoE and 4 standard 10/100Mbps ports
Flow Control for Full-Duplex mode
Lifetime Warranty*

SPEC
Standard
IEEE 802.3 10Base-T
IEEE802.3u 100Base-TX
IEEE 802.3af Power over Ethernet
Network Media
10Mbps: Cat 3,4,5 Unshielded Cable
100Mbps: Cat 5, 5E, 6 Unshielded Cable
Protocol / Topology
CSMA/CD ; Star
Ports
4 x 10/100Mbps Auto-MDIX POE Ports (1~4)
4 x 10/100Mbps Auto-MDIX Fast Ethernet Ports (5 ~8)
Data Transfer Rate
Ethernet: 10/20Mbps (half/full duplex)
Fast Ethernet: 100/200Mbps (half/full duplex)
RAM Buffer / Filtering
96 Kbytes / 1K entry per device
Power
48V DC 0.8A External Power Adapter
Diagnostic LEDs
Per Unit: Power, Power MAX
Per Port: Link/Activity, Speed
PoE: PoE Status, Link/Activity, Speed
Power Consumption
6.3 watts max (no PD Device connected)
36.3 watts max (with 30w PoE Device connected)
Temperature
Operating: 0° ~ 40°C (32° ~ 104°F)
Storage: -10° ~ 70°C (14° ~ 158°F)
Humidity
10%- 90% (non-condensing)
Dimensions
171 x 98 x 29mm (6.7 x 3.7 x 1.1in.)
Weight
430g (13.8oz.)
Certification
FCC, CE
