Install a non-PoE device in a remote location
Splits a Gigabit PoE signal into separate power and Gigabit data sources
Set the output power to either 5 V, 7.5 V, 9 V, or 12 V
Use this compact device with TRENDnet PoE switches or injectors
Save on installation and equipment costs

SPEC
Standards
IEEE 802.3
IEEE 802.3u
IEEE 802.3x
IEEE 802.3ab
IEEE 802.3af
Device Interface
1 x Gigabit data/power in port
1 x Gigabit data out port
1 x Power out port
LED indicators
Adjustable output power DIP switch (5 V, 7.5 V, 9 V, 12 V)
Data Transfer Rate
Ethernet: 10 Mbps (half duplex), 20 Mbps (full duplex)
Fast Ethernet: 100 Mbps (half duplex), 200 Mbps (full duplex)
Gigabit: 2000 Mbps (full duplex)
Jumper Cable
2.0 to 2.0 mm
2.0 to 2.5 mm
Power
PoE network cable input: 48 V DC, 0.38 A
Output: 5 V (2 A), 7.5 V (2 A), 9 V (1.7 A), 12 V (1.2 A)
Consumption: 0.3 Watts (max.)
Operating Temperature
0 – 45 °C (32 - 113 °F)
Operating Humidity
Max. 90% non-condensing
Dimensions
70 x 45 x 25 mm (2.8 x 1.8 x 1 in.)
Weight
60 g (2.1 oz.)
Certifications
CE
FCC
Warranty
3 year limited
